ELECTRICITY SYSTEM 1GROUP - EX45H-T935B

Kioti TRACTOR | DK Series | DK50HSE

Diagram for ELECTRICITY SYSTEM 1GROUP - EX45H-T935B
  • 1

    ASSY PLATE,METER v

    • Part No. T4025-69012
    • Applied Dates 2008-07-18 and up
    • Serial No. HS2800001 to KS2800052
    • *multiple options for # 1
    • 1 shown on diagram
    $419.99
  • 1 Instrument Assy

    Instrument Assy

    • Part No. T4025-69013
    • Compatibility New Replaces Old
    • Applied Dates 2010-10-31 and up
    • Serial No. KS2800053 and up
    • *multiple options for # 1
    • 1 shown on diagram
    $684.99
  • 1

    Instrument Assy

    • Part No. T4025-69014
    • Compatibility New Replaces Old
    • *multiple options for # 1
    • 1 shown on diagram
    $684.99
  • 2

    BULB dnr v

    • Part No. T4684-69021004
    • 12V3.4W
    • 2 shown on diagram
    $6.99
  • 3

    BULB v

    • Part No. T2185-00101
    • Applied Dates 2007-03-20 to 2008-07-17
    • 14V 1.4W
    • 16 shown on diagram
    $5.49
  • 4

    LAMP dnr v

    • Part No. T4710-69021013
    • 14V3W
    • 1 shown on diagram
    $7.49
  • 5

    SCREW

    • Part No. 03024-50414
    • M4XP0.7
    • 6 shown on diagram
    $0.68
  • 6

    Nut M4XP0.7 (02054-50040)

    • Part No. 02054-50040
    • M4XP0.7
    • 6 shown on diagram
    $0.61
  • 7

    COVER

    • Part No. T4025-68511
    • 1 shown on diagram
    $19.99
  • 8

    Starter Switch, Replaced by T4520-75176

    • Part No. T4520-75174
    • Applied Dates Up to 2009-12-31
    • Serial No. Up to JS2800056
    • *multiple options for # 8
    • 1 shown on diagram
    $0.00
  • 8 Ignition Starter Switch, w/o Key

    Ignition Starter Switch, w/o Key

    • Part No. T4520-75176
    • Compatibility New Replaces Old
    • Applied Dates 2010-07-29 and up
    • Serial No. KS2800025 to LS2800040
    • *multiple options for # 8
    • 1 shown on diagram
    $99.99
  • 8

    Starter Switch (T5515-75171)

    • Part No. T5515-75171
    • Compatibility Call for compatibility
    • Applied Dates 2012-01-01 to 2012-05-31
    • Serial No. MS2800001 to MS2800044
    • *multiple options for # 8
    • 1 shown on diagram
    $89.99
  • 8 Ignition Switch w/ Shutter (Epoxy filled), Replaced by TF15-0196A

    Ignition Switch w/ Shutter (Epoxy filled), Replaced by TF15-0196A

    • Part No. T5520-75171
    • Compatibility Call for compatibility
    • Applied Dates 2014-02-01 and up
    • Serial No. PS2800005 and up
    • *multiple options for # 8
    • 1 shown on diagram
    $0.00
  • 8 Ignition Starter Switch With Shutter

    Ignition Starter Switch With Shutter

    • Part No. TF15-0196A
    • Compatibility Interchngable
    • *multiple options for # 8
    • 1 shown on diagram
    $119.99
  • 9 WATERPROOF COVER, STARTING SWITCH, CLEAR, Replaced by T4837-77774

    WATERPROOF COVER, STARTING SWITCH, CLEAR, Replaced by T4837-77774

    • Part No. T4837-77772
    • Applied Dates Up to 2007-03-23
    • *multiple options for # 9
    • 1 shown on diagram
    $3.49
  • 9

    Starter Switch Waterproof Cover (T4837-77773)

    • Part No. T4837-77773
    • Compatibility New Replaces Old
    • *multiple options for # 9
    • 1 shown on diagram
    $5.99
  • 9 COVER STARTER SWITCH WATERPROOF, BLACK

    COVER STARTER SWITCH WATERPROOF, BLACK

    • Part No. T4837-77774
    • Compatibility New Replaces Old
    • *multiple options for # 9
    • 1 shown on diagram
    $5.99
  • 10 Kioti Ignition Keys, Trapezoid Handle, Double Cut Blade, Set of 2

    Kioti Ignition Keys, Trapezoid Handle, Double Cut Blade, Set of 2

    • Part No. T4625-75191
    • 1 shown on diagram
    $16.99
  • 11

    COMBINATION SWITCH ASSY, Replaced by T2368-69025

    • Part No. T2368-69023
    • Applied Dates 2008-03-09 to 2013-03-30
    • Serial No. HS2800001 to NS2800004
    • *multiple options for # 11
    • 1 shown on diagram
    $0.00
  • 11 Assy Combination Switch 9 Pin

    Assy Combination Switch 9 Pin

    • Part No. T2368-69025
    • Compatibility New Replaces Old
    • Applied Dates 2015-01-01 and up
    • Serial No. RS2800001 and up
    • *multiple options for # 11
    • 1 shown on diagram
    $139.99
  • 12 SWITCH, EMERGENCY LAM

    SWITCH, EMERGENCY LAM

    • Part No. T4025-68351
    • 1 shown on diagram
    $83.99
  • 13 SWITCH

    SWITCH

    • Part No. T4025-68311
    • 1 shown on diagram
    $81.99
  • 14 SWITCH, PTO AUTO PASSIVE

    SWITCH, PTO AUTO PASSIVE

    • Part No. T4025-68361
    • 1 shown on diagram
    $89.99
  • 15

    SWITCH, 4WD

    • Part No. T4025-68291
    • 1 shown on diagram
    $84.99
  • 16 ASS’Y PTO SWITCH

    ASS’Y PTO SWITCH

    • Part No. T4025-68371
    • 1 shown on diagram
    $78.99
  • 17

    BESEL(CENTER)

    • Part No. T4025-68381
    • 1 shown on diagram
    $8.49
  • 18

    BESEL(SIDE)

    • Part No. T4025-68391
    • 4 shown on diagram
    $7.49
  • 19

    HOLDER, MATER v, Replaced by T4121-69611BB

    • Part No. T4121-69611
    • Serial No. Up to GS2800002
    • t1.6
    • *multiple options for # 19
    • 1 shown on diagram
    $0.00
  • 19

    HOLDER, INSTRUMENT v

    • Part No. T4121-69611BB
    • Compatibility No Interchange
    • Serial No. HS2800001 and up
    • *multiple options for # 19
    • 1 shown on diagram
    $26.99
  • 20 TAPPING SCREW v

    TAPPING SCREW v

    • Part No. 38240-1883-1
    • M4X16
    • 4 shown on diagram
    $0.79
