SUCTION LINE GROUP - TD2-G411001

Kioti TRACTOR | DK Series | DK5010

Diagram for SUCTION LINE GROUP - TD2-G411001
  • 1

    BOLT, WASHER

    • Part No. 01023-50620
    • Applied Dates Up to 2016-12-16
    • M6XP1.0
    • 4 shown on diagram
    $1.39
  • 2 Bolt With Washer, M8 P1.25 x 20mm

    Bolt With Washer, M8 P1.25 x 20mm

    • Part No. 01123-50820
    • M8XP1.25
    • 2 shown on diagram
    $2.49
  • 3

    BOLT

    • Part No. 01127-50820
    • Applied Dates Up to 2016-12-16
    • 1 shown on diagram
    $2.49
  • 4 O RING

    O RING

    • Part No. 04810-00280
    • Applied Dates Up to 2016-12-16
    • DIA27.7
    • 1 shown on diagram
    $1.09
  • 5 O-ring

    O-ring

    • Part No. 04810-00320
    • Applied Dates Up to 2016-12-16
    • 1 shown on diagram
    $1.39
  • 6

    BAND, HOSE

    • Part No. T4340-38231
    • Applied Dates Up to 2017-03-07
    • Serial No. Up to TR8000040
    • ??45#
    • *multiple options for # 6
    • 2 shown on diagram
    $4.49
  • 6

    CLAMP,HOSESTAINLESS32-50

    • Part No. CE11-0011A
    • Compatibility Interchangeable
    • Applied Dates 2017-07-01 to 2017-03-07
    • Serial No. TR8000041 to WR8000028
    • 32-50mm
    • *multiple options for # 6
    • 2 shown on diagram
    $3.49
  • 7 HOSE, INLET

    HOSE, INLET

    • Part No. T4520-38151
    • Applied Dates Up to 2016-12-16
    • 1 shown on diagram
    $13.99
  • 8

    MAGNETIC ASS`Y

    • Part No. T4810-46751
    • 1 shown on diagram
    $72.99
  • 9

    JOINT CARTRIDGE

    • Part No. T4810-46762
    • 1 shown on diagram
    $16.99
  • 10

    TUBE, INLET

    • Part No. T5710-36511
    • Applied Dates Up to 2016-12-16
    • 1 shown on diagram
    $169.99
  • 11

    TUBE

    • Part No. T5710-36612
    • Applied Dates Up to 2016-12-16
    • 1 shown on diagram
    $91.99
  • 12 Hydraulic Filter

    Hydraulic Filter

    • Part No. T5710-38031
    • Applied Dates 2015-07-23 to 2018-01-03
    • 1 shown on diagram
    $45.99
