BATTERY GROUP - TD2-G513501

Kioti TRACTOR | DK Series | DK5010

Diagram for BATTERY GROUP - TD2-G513501
  • 1

    HOUSING, FLYWHEEL dnr v

    • Part No. T5710-69161
    • Serial No. Up to XR8000166
    • *multiple options for # 1
    • 1 shown on diagram
    $134.99
  • 1

    ASSY CABLE, BATTERY POS

    • Part No. TD25-0186A
    • Compatibility New Replaces Old
    • *multiple options for # 1
    • 1 shown on diagram
    $124.99
  • 2

    WIRE, BATTERY (-), Replaced by T5710-69615

    • Part No. T5710-69614
    • Applied Dates 2015-06-24 to 2019-10-20
    • Serial No. RR8000001 to VR8000126
    • *multiple options for # 2
    • 1 shown on diagram
    $0.00
  • 2

    WIRE,BATTERY (-)

    • Part No. T5710-69615
    • Compatibility New Replaces Old
    • Applied Dates 2019-10-21 and up
    • Serial No. VR8000127 to WR8000028
    • *multiple options for # 2
    • 1 shown on diagram
    $74.99
  • 2

    CABLE, BATTERY EARTH

    • Part No. TD25-0189A
    • Compatibility New Replaces Old
    • *multiple options for # 2
    • 1 shown on diagram
    $0.00
  • 3 BOLT, FLANGE

    BOLT, FLANGE

    • Part No. 01754-50812
    • M8XP1.25
    • 1 shown on diagram
    $1.79
  • 4 Nut M8 P1.25

    Nut M8 P1.25

    • Part No. 02156-50080
    • M8XP1.25
    • 1 shown on diagram
    $0.85
  • 5 Spring Lock Washer M8

    Spring Lock Washer M8

    • Part No. 04512-50080
    • M08
    • 1 shown on diagram
    $0.61
