AUX SPEED SHIFT LEVER GROUP - EX45M-T375A

Kioti TRACTOR | DK Series | DK50SE

Diagram for AUX SPEED SHIFT LEVER GROUP - EX45M-T375A
  • 1

    SPACER

    • Part No. T4115-60751
    • 1 shown on diagram
    $8.49
  • 2

    LEVER

    • Part No. T4115-60542
    • 1 shown on diagram
    $91.99
  • 3

    ROD v, Replaced by T4115-60551

    • Part No. T4115-60531
    • Applied Dates Up to 2008-10-05
    • *multiple options for # 3
    • 1 shown on diagram
    $0.00
  • 3 ROD HI LO v

    ROD HI LO v

    • Part No. T4115-60551
    • Compatibility Interchangeable
    • Applied Dates 2009-07-01 and up
    • Serial No. JS9600001 and up
    • *multiple options for # 3
    • 1 shown on diagram
    $44.99
  • 3 ROD,(HI-LO)

    ROD,(HI-LO)

    • Part No. T4115-60552
    • Compatibility Interchangeable
    • *multiple options for # 3
    • 1 shown on diagram
    $45.99
  • 4 Spring Lock Washer M8

    Spring Lock Washer M8

    • Part No. 04512-50080
    • Applied Dates Up to 2008-10-05
    • M08
    • 2 shown on diagram
    $0.61
  • 5 NUT

    NUT

    • Part No. 02114-50080
    • Applied Dates Up to 2007-12-31
    • M8*P1.25
    • *multiple options for # 5
    • 2 shown on diagram
    $0.67
  • 5

    PIN, SNAP

    • Part No. 05515-51000
    • Compatibility Interchangeable
    • DIA10
    • *multiple options for # 5
    • 2 shown on diagram
    $1.29
  • 6

    GRIP

    • Part No. T2350-24462
    • 1 shown on diagram
    $9.99
  • 7 Flat Washer M18

    Flat Washer M18

    • Part No. 04011-50180
    • M18
    • 1 shown on diagram
    $1.59
  • 8 Snap Ring

    Snap Ring

    • Part No. 04612-00180
    • DIA18
    • 1 shown on diagram
    $1.09
