SUN ROOF GROUP - D52-T690E

Kioti TRACTOR | DK Series | DK65C

  • 1

    TRK – SUN ROOF obs v

    • Part No. T4815-82991
    • 1 shown on diagram
    $569.99
  • 2

    BRACKET, HINGE

    • Part No. T4681-88361
    • 2 shown on diagram
    $16.99
  • 3

    BRACKET,HINGE

    • Part No. T4681-88031
    • 2 shown on diagram
    $17.99
  • 4

    Hinge Pin ( T4620-88051 )

    • Part No. T4620-88051
    • 2 shown on diagram
    $2.99
  • 5 RING SNAP

    RING SNAP

    • Part No. 04613-50100
    • 2 shown on diagram
    $0.49
  • 6 Spacer

    Spacer

    • Part No. T4620-81351
    • 2 shown on diagram
    $4.99
  • 7 Packing, 1 T4520-87402

    Packing, 1 T4520-87402

    • Part No. T4520-87402
    • T3
    • 4 shown on diagram
    $2.99
  • 8 Flat Washer M8

    Flat Washer M8

    • Part No. 04015-50080
    • M8
    • 2 shown on diagram
    $1.09
  • 9 NUT, Replaced by 02156-50080

    NUT, Replaced by 02156-50080

    • Part No. 02056-50080
    • 2 shown on diagram
    $0.45
  • 10

    BRACKET,CYLINDER(LH)

    • Part No. T4810-88191
    • 1 shown on diagram
    $9.49
  • 11

    BRACKET,CYLINDER(RH)

    • Part No. T4810-88181
    • 1 shown on diagram
    $9.99
  • 12 Bolt, Flange M8 P1.25

    Bolt, Flange M8 P1.25

    • Part No. 01754-50830
    • M8XP1.25
    • 4 shown on diagram
    $1.89
  • 13 COLLAR PACKING

    COLLAR PACKING

    • Part No. T4520-87412
    • 4 shown on diagram
    $3.49
  • 14 Spacer

    Spacer

    • Part No. T4620-81351
    • 4 shown on diagram
    $4.99
  • 15 Flat Washer M8

    Flat Washer M8

    • Part No. 04015-50080
    • M8
    • 4 shown on diagram
    $1.09
  • 16 Packing, 1 T4520-87402

    Packing, 1 T4520-87402

    • Part No. T4520-87402
    • T3
    • 4 shown on diagram
    $2.99
  • 17 AIR CYLINDER v

    AIR CYLINDER v

    • Part No. T4681-89192
    • 2 shown on diagram
    $109.99
  • 18 Spring Lock Washer M8

    Spring Lock Washer M8

    • Part No. 04512-50080
    • M08
    • 2 shown on diagram
    $0.61
  • 19 Flat Washer M8

    Flat Washer M8

    • Part No. 04013-50080
    • 2 shown on diagram
    $0.79
  • 20 NUT, Replaced by 02156-50080

    NUT, Replaced by 02156-50080

    • Part No. 02056-50080
    • 2 shown on diagram
    $0.45
  • 21 Flat Washer M8

    Flat Washer M8

    • Part No. 04015-50080
    • M8
    • 4 shown on diagram
    $1.09
  • 22 COLLAR PACKING

    COLLAR PACKING

    • Part No. T4520-87412
    • 4 shown on diagram
    $3.49
  • 23 Packing, 1 T4520-87402

    Packing, 1 T4520-87402

    • Part No. T4520-87402
    • T3
    • 2 shown on diagram
    $2.99
  • 24 Spacer

    Spacer

    • Part No. T4620-81351
    • 2 shown on diagram
    $4.99
  • 25 NUT, Replaced by 02156-50080

    NUT, Replaced by 02156-50080

    • Part No. 02056-50080
    • 2 shown on diagram
    $0.45
  • 26 Cap Nut, M8 T4815-93211

    Cap Nut, M8 T4815-93211

    • Part No. T4815-93211
    • M8
    • 2 shown on diagram
    $1.49
  • 27 Bolt, Flange M8 P1.25

    Bolt, Flange M8 P1.25

    • Part No. 01754-50830
    • M8XP1.25
    • 2 shown on diagram
    $1.89
  • 28 Flat Washer M8

    Flat Washer M8

    • Part No. 04015-50080
    • M8
    • 2 shown on diagram
    $1.09
  • 29 COLLAR PACKING

    COLLAR PACKING

    • Part No. T4520-87412
    • 2 shown on diagram
    $3.49
  • 30 Packing, 1 T4520-87402

    Packing, 1 T4520-87402

    • Part No. T4520-87402
    • T3
    • 2 shown on diagram
    $2.99
  • 31 Spacer

    Spacer

    • Part No. T4620-81351
    • 2 shown on diagram
    $4.99
  • 32

    GRIP, SUNROOF, Replaced by T4686-83521

    • Part No. T4681-83521
    • 1 shown on diagram
    $0.00
  • 33 Packing, 1 T4520-87402

    Packing, 1 T4520-87402

    • Part No. T4520-87402
    • T3
    • 2 shown on diagram
    $2.99
  • 34

    COLLAR

    • Part No. T4520-97431
    • 2 shown on diagram
    $1.89
  • 35 PACKING

    PACKING

    • Part No. T4520-88401
    • 2 shown on diagram
    $3.49
  • 36 Flat Washer M6, Replaced by 04012-50060

    Flat Washer M6, Replaced by 04012-50060

    • Part No. 04015-50060
    • M6
    • 2 shown on diagram
    $0.00
  • 37 NUT

    NUT

    • Part No. 02056-50060
    • M6XP1.0
    • 2 shown on diagram
    $0.49
  • 38

    BOLT

    • Part No. T4681-83531
    • 2 shown on diagram
    $1.79
  • 39 NUT CAP M6

    NUT CAP M6

    • Part No. T4680-93211
    • 2 shown on diagram
    $1.29
  • 40

    BRACKET

    • Part No. T4681-83541
    • 1 shown on diagram
    $16.99
  • 41 Bolt, Flange M8 P1.25

    Bolt, Flange M8 P1.25

    • Part No. 01754-50830
    • M8XP1.25
    • 2 shown on diagram
    $1.89
  • 42 COLLAR PACKING

    COLLAR PACKING

    • Part No. T4520-87412
    • 2 shown on diagram
    $3.49
  • 43 Flat Washer M8

    Flat Washer M8

    • Part No. 04015-50080
    • M8
    • 4 shown on diagram
    $1.09
  • 44 Spacer

    Spacer

    • Part No. T4620-81351
    • 2 shown on diagram
    $4.99
  • 45 NUT, Replaced by 02156-50080

    NUT, Replaced by 02156-50080

    • Part No. 02056-50080
    • 2 shown on diagram
    $0.45
