PROPER SHAFT GROUP - D62-T290A

Kioti TRACTOR | DK Series | DK65C

  • 1

    COVER 1, PROPELLER SHAFT, Replaced by T4810-24653BB

    • Part No. T4810-24651
    • Applied Dates Up to 2007-10-21
    • 1 shown on diagram
    $0.00
  • 2 PACKING

    PACKING

    • Part No. T4810-24621
    • Applied Dates Up to 2006-07-19
    • T0.5
    • 1 shown on diagram
    $6.49
  • 3 Bolt With Washer, M8 P1.25 x 20mm

    Bolt With Washer, M8 P1.25 x 20mm

    • Part No. 01123-50820
    • M8XP1.25
    • 2 shown on diagram
    $2.49
  • 4

    COUPLING

    • Part No. T4810-24662
    • 2 shown on diagram
    $53.99
  • 5

    PIN, SPRING

    • Part No. 05411-00838
    • Applied Dates 1999-04-12 and up
    • 2 shown on diagram
    $1.49
  • 6

    SHAFT 3,FRONT DRIVE

    • Part No. T4810-24671
    • 1 shown on diagram
    $224.99
  • 7 O RING

    O RING

    • Part No. 04811-00460
    • 1 shown on diagram
    $1.29
  • 8

    COVER, PROPELLER SHAFT-2 dnr v

    • Part No. T4810-24691
    • 1 shown on diagram
    $72.99
  • 9 Bolt With Washer, M8 P1.25 x 20mm

    Bolt With Washer, M8 P1.25 x 20mm

    • Part No. 01123-50820
    • M8XP1.25
    • 1 shown on diagram
    $2.49
  • 10 O RING

    O RING

    • Part No. 04811-00420
    • DIA41.7
    • 2 shown on diagram
    $1.19
