FUEL TANK GROUP - DK754EU-T485A

Kioti TRACTOR | DK Series | DK754C

  • 1

    TANK, FUEL RH v

    • Part No. T4935-55032
    • Applied Dates 2007-06-04 to 2008-06-11
    • Serial No. Up to HH2400018
    • *multiple options for # 1
    • 1 shown on diagram
    $444.99
  • 1

    TANK, FUEL RH V, Replaced by T4935-55034BB

    • Part No. T4935-55033
    • Compatibility New Replaces Old
    • Applied Dates 2008-06-12 to 2009-01-15
    • Serial No. Up to HH2400018
    • *multiple options for # 1
    • 1 shown on diagram
    $0.00
  • 1

    FUEL TANK

    • Part No. T4935-55034BB
    • Compatibility New Replaces Old
    • Applied Dates 2009-02-20 and up
    • Serial No. JH2400001 and up
    • *multiple options for # 1
    • 1 shown on diagram
    $699.99
  • 2

    TANK, FUEL LH v

    • Part No. T4935-55023
    • Applied Dates 2008-01-01 to 2008-10-01
    • Serial No. Up to HH2400018
    • *multiple options for # 2
    • 1 shown on diagram
    $379.99
  • 2

    TANK FUEL LH v

    • Part No. T4935-55025
    • Compatibility New Replaces Old
    • Applied Dates 2009-01-12 to 2010-04-03
    • Serial No. JH2400016 and up
    • *multiple options for # 2
    • 1 shown on diagram
    $399.99
  • 2

    FUEL, TANK LH v, Replaced by T4920-55023

    • Part No. T4920-55022
    • Compatibility Call for compatibility
    • Applied Dates 2010-04-04 to 2013-04-14
    • Serial No. KH2400001 and up
    • *multiple options for # 2
    • 1 shown on diagram
    $0.00
  • 2 FUEL TANK LH v

    FUEL TANK LH v

    • Part No. T4920-55023
    • Compatibility New Replaces Old
    • Applied Dates 2013-04-15 and up
    • *multiple options for # 2
    • 1 shown on diagram
    $824.99
  • 3 HOSE 1, FUEL RH

    HOSE 1, FUEL RH

    • Part No. T4935-55161
    • 1 shown on diagram
    $52.99
  • 4 Fuel Hose 2

    Fuel Hose 2

    • Part No. T4935-55171
    • 1 shown on diagram
    $58.99
  • 5

    BAND, HOSE

    • Part No. T2540-38251
    • ??51#
    • 4 shown on diagram
    $4.99
  • 6 TUBE, FUEL

    TUBE, FUEL

    • Part No. T4935-55092
    • 1 shown on diagram
    $45.99
  • 7

    SUPPORT 1, FUEL TANK

    • Part No. T4935-55071
    • Applied Dates 2010-05-13 to 2011-08-31
    • Serial No. KH2400001 and up
    • *multiple options for # 7
    • 1 shown on diagram
    $179.99
  • 7

    SUPPORT 1, FUEL TANK TAG

    • Part No. T4935-55072
    • Compatibility New Replaces Old
    • Applied Dates 2011-09-01 and up
    • Serial No. LH2400001 and up
    • *multiple options for # 7
    • 1 shown on diagram
    $224.99
  • 8

    SUPPORT 2, FUEL TANK

    • Part No. T4935-55081
    • Applied Dates 2010-05-13 to 2011-08-31
    • Serial No. KH2400001 and up
    • *multiple options for # 8
    • 1 shown on diagram
    $164.99
  • 8

    SUPPORT 2, FUEL TANK TAG

    • Part No. T4935-55082
    • Compatibility New Replaces Old
    • Applied Dates 2011-09-01 and up
    • Serial No. LH2400001 and up
    • *multiple options for # 8
    • 1 shown on diagram
    $209.99
  • 9

    BOLT

    • Part No. 01073-51430
    • Applied Dates Up to 2008-03-23
    • *multiple options for # 9
    • 4 shown on diagram
    $2.99
  • 9

    Bolt M14 P1.50x30mm

    • Part No. 01173-51430
    • Compatibility Call for compatibility
    • Applied Dates 2010-04-04 to 2010-04-04
    • Serial No. KH2400001 and up
    • M14P1.5*30
    • *multiple options for # 9
    • 4 shown on diagram
    $4.49
  • 9

    Bolt M14 P1.50x30mm

    • Part No. 01173-51430
    • Compatibility Interchngable
    • M14P1.5*30
    • *multiple options for # 9
    • 2 shown on diagram
    $4.49
  • 10

    M14 Spring Lock Washer 04512-50140

    • Part No. 04512-50140
    • M14
    • 4 shown on diagram
    $0.90
  • 11

    HOLDER 1, FUEL TANK, Replaced by T4935-55043BB

    • Part No. T4935-55042
    • Applied Dates 2007-06-04 to 2007-12-20
    • *multiple options for # 11
    • 2 shown on diagram
    $28.59
  • 11

    PLATE, FUEL TANK HOLDER-1 dnr v, Replaced by T4935-55043BB

    • Part No. T4935-55043
    • Compatibility Interchngable
    • Applied Dates 2010-04-04 to 2010-04-03
    • Serial No. KH2400001 and up
    • *multiple options for # 11
    • 2 shown on diagram
    $0.00
  • 11

    PLATE, FUEL TANK HOLDER-1 dnr v, Replaced by T4935-55043BB

    • Part No. T4935-55043
    • Compatibility Call for compatibility
    • Serial No. KH2400001 and up
    • *multiple options for # 11
    • 1 shown on diagram
    $0.00
  • 12

    Bolt, M8 P1.25 x 50mm

    • Part No. 01153-50850
    • M8*P1.25
    • 2 shown on diagram
    $2.49
  • 13 Kioti Flange Nut, M8 P1.25

    Kioti Flange Nut, M8 P1.25

    • Part No. 02751-50080
    • M8XP1.25
    • 2 shown on diagram
    $0.67
  • 14 RUBBER, CUSHION v

    RUBBER, CUSHION v

    • Part No. T4810-55312
    • 4 shown on diagram
    $2.49
  • 15

    RUBBER, BATTERY CUSHION v

    • Part No. T4520-33401
    • Applied Dates Up to 2008-04-29
    • *multiple options for # 15
    • 10 shown on diagram
    $8.49
  • 15 RUBBER, CUSHION v

    RUBBER, CUSHION v

    • Part No. T2610-50271
    • Compatibility Call for compatibility
    • Applied Dates 2010-10-31 to 2010-10-30
    • Serial No. KH2400004 to KH2400003
    • *multiple options for # 15
    • 10 shown on diagram
    $5.99
  • 15 RUBBER, CUSHION v

    RUBBER, CUSHION v

    • Part No. T2610-50271
    • Compatibility New Replaces Old
    • *multiple options for # 15
    • 2 shown on diagram
    $5.99
  • 16

    RUBBER,BATTERY CUSHION dnr v

    • Part No. T4810-50351
    • Applied Dates Up to 2008-04-29
    • *multiple options for # 16
    • 2 shown on diagram
    $9.49
  • 16 RUBBER, CUSHION v

    RUBBER, CUSHION v

    • Part No. T2610-50271
    • Compatibility Call for compatibility
    • Serial No. Up to KH2400003
    • *multiple options for # 16
    • 2 shown on diagram
    $5.99
  • 17

    PLATE, FUEL TANK HOLDER-2 dnr v, Replaced by T4935-55043BB

    • Part No. T4935-55051
    • Applied Dates Up to 2007-12-20
    • *multiple options for # 17
    • 2 shown on diagram
    $0.00
  • 17

    HOLDER 2, FUEL TANK, Replaced by T4935-55043BB

    • Part No. T4935-55052
    • Compatibility Interchngable
    • Applied Dates 2007-12-21 to 2012-10-27
    • *multiple options for # 17
    • 2 shown on diagram
    $0.00
  • 18 Lock Washer M10

    Lock Washer M10

    • Part No. 04512-50100
    • M10
    • 6 shown on diagram
    $0.79
  • 19 Nut M10 P1.25

    Nut M10 P1.25

    • Part No. 02176-50100
    • M10XP1.25
    • 12 shown on diagram
    $0.98
  • 20

    FUEL SENDER ASSY v, Replaced by T4935-69213

    • Part No. T4935-69212
    • Applied Dates 2007-08-17 to 2012-09-30
    • *multiple options for # 20
    • 1 shown on diagram
    $0.00
  • 20 FUEL SENDOR v

    FUEL SENDOR v

    • Part No. T4935-69213
    • Compatibility New Replaces Old
    • Applied Dates 2012-10-01 and up
    • *multiple options for # 20
    • 1 shown on diagram
    $99.99
  • 21

    WASHER, SPRING

    • Part No. 04512-50040
    • M04
    • 5 shown on diagram
    $0.55
  • 22

    Nut M4XP0.7 (02054-50040)

    • Part No. 02054-50040
    • M4XP0.7
    • 5 shown on diagram
    $0.61
  • 23

    FUEL CAP ASSY, Replaced by T2611-54825

    • Part No. T2611-54822
    • Applied Dates Up to 2008-10-05
    • Serial No. Up to HH2400018
    • *multiple options for # 23
    • 1 shown on diagram
    $41.83
  • 23

    Fuel Cap Assy Replaced by T2611-54825

    • Part No. T2611-54823
    • Compatibility New Replaces Old
    • *multiple options for # 23
    • 1 shown on diagram
    $0.00
  • 24

    AIR BREATHER

    • Part No. T4935-55221
    • Applied Dates 2008-04-19 to 2008-08-09
    • Serial No. HH2400001 to HH2400018
    • *multiple options for # 24
    • 2 shown on diagram
    $21.99
  • 24

    AIR BREATHER

    • Part No. T4935-55221
    • Compatibility New Replaces Old
    • *multiple options for # 24
    • 1 shown on diagram
    $21.99
  • 25

    CONNECTOR, AIR BREATHER RH

    • Part No. T4930-55321
    • 1 shown on diagram
    $13.99
  • 26

    CLAMP, HOSE

    • Part No. 09318-88160
    • DIA16
    • 4 shown on diagram
    $1.29
  • 27 Bolt With Washer, M8 P1.25 x 16mm

    Bolt With Washer, M8 P1.25 x 16mm

    • Part No. 01123-50816
    • M8XP1.25
    • 2 shown on diagram
    $1.09
  • 28

    COVER 1, FUEL TANK, Replaced by T4935-55121BB

    • Part No. T4935-55121
    • 1 shown on diagram
    $0.00
  • 29

    COVER 2, FUEL TANK

    • Part No. T4935-55131
    • 1 shown on diagram
    $144.99
  • 30

    COVER 3, FUEL TANK

    • Part No. T4935-55141
    • 1 shown on diagram
    $56.99
  • 31

    COVER 4, FUEL TANK v

    • Part No. T4935-55151
    • Applied Dates Up to 2009-03-16
    • Serial No. Up to HH2400018
    • *multiple options for # 31
    • 2 shown on diagram
    $28.99
  • 31

    COVER 4, FUEL TANK, Replaced by T4935-55152BB

    • Part No. T4935-55152
    • Compatibility New Replaces Old
    • Applied Dates 2009-04-01 to 2011-08-31
    • Serial No. JH2400043 and up
    • *multiple options for # 31
    • 2 shown on diagram
    $0.00
  • 31

    COVER, FUEL-TANK dnr v

    • Part No. T4920-55151
    • Compatibility Call for compatibility
    • Applied Dates 2011-09-01 to 2011-09-01
    • T1.2
    • *multiple options for # 31
    • 1 shown on diagram
    $174.99
  • 32

    Bolt w/Lock Washer M10 P1.25x20mm

    • Part No. 01133-51020
    • M10XP1.25
    • 6 shown on diagram
    $2.99
  • 33 Bolt, Washer

    Bolt, Washer

    • Part No. 01135-51020
    • M10*1.25
    • 4 shown on diagram
    $1.99
  • 34 BOLT

    BOLT

    • Part No. 01127-50820
    • 4 shown on diagram
    $2.49
  • 35 STRAINER,FUEL

    STRAINER,FUEL

    • Part No. T4686-41351
    • 1 shown on diagram
    $8.99
  • 36

    HOLDER 1, FUEL TANK

    • Part No. T4920-55041
    • 1 shown on diagram
    $169.99
  • 37

    STUD

    • Part No. 01517-51430
    • 1 shown on diagram
    $7.99
  • 38 Nut M14 P1.50

    Nut M14 P1.50

    • Part No. 02176-50140
    • M14XP1.5
    • 1 shown on diagram
    $1.79
  • 39

    RUBBER

    • Part No. T5270-55241
    • 8 shown on diagram
    $13.99
