ROOF GROUP - DK902-T850E

Kioti TRACTOR | DK Series | DK754C

  • 1

    NLA- ROOF ASS`Y v

    • Part No. T4930-82001
    • Serial No. Up to KH2400003
    • *multiple options for # 1
    • 1 shown on diagram
    $1,699.99
  • 1

    ASSY,ROOF

    • Part No. T5310-81001
    • Compatibility No Interchange
    • Serial No. MH2400001 and up
    • *multiple options for # 1
    • 1 shown on diagram
    $0.00
  • 1

    ASSY ROOF v

    • Part No. T5310-81002
    • Compatibility Interchngable
    • *multiple options for # 1
    • 1 shown on diagram
    $1,799.99
  • 1

    TRK- ASSY ROOF dnr v

    • Part No. T5310-81003
    • Compatibility Interchngable
    • *multiple options for # 1
    • 1 shown on diagram
    $2,739.99
  • 2

    ROOF v

    • Part No. T4930-81991
    • Serial No. Up to KH2400003
    • *multiple options for # 2
    • 1 shown on diagram
    $569.99
  • 2

    ROOF, INNER

    • Part No. T5310-81991
    • Compatibility No Interchange
    • Serial No. MH2400001 and up
    • *multiple options for # 2
    • 1 shown on diagram
    $0.00
  • 3

    ROOF v [NLA]

    • Part No. T4930-81981
    • Serial No. Up to KH2400003
    • *multiple options for # 3
    • 1 shown on diagram
    $0.00
  • 3

    ROOF OUT v

    • Part No. T5310-82001
    • Compatibility No Interchange
    • Serial No. MH2400001 and up
    • *multiple options for # 3
    • 1 shown on diagram
    $1,299.99
  • 4

    SPACER 2, ROOF

    • Part No. T5310-83921
    • 4 shown on diagram
    $13.99
  • 5 Flat Washer M8

    Flat Washer M8

    • Part No. 04015-50080
    • M8
    • 4 shown on diagram
    $1.09
  • 6 Bolt, Flange M8 P1.25

    Bolt, Flange M8 P1.25

    • Part No. 01754-50830
    • M8XP1.25
    • 4 shown on diagram
    $1.89
  • 7 WASHER PACKING v

    WASHER PACKING v

    • Part No. T4833-87141
    • 4 shown on diagram
    $2.49
  • 8

    SPONGE

    • Part No. T4145-81951
    • 2 shown on diagram
    $24.99
  • 9 Flat Washer M6

    Flat Washer M6

    • Part No. 04013-50060
    • M6
    • 9 shown on diagram
    $0.73
  • 10 FLANGE BOLT, HEX HEAD M8

    FLANGE BOLT, HEX HEAD M8

    • Part No. 01754-50820
    • M8XP1.25
    • 2 shown on diagram
    $1.19
  • 11 Flat Washer M8

    Flat Washer M8

    • Part No. 04015-50080
    • M8
    • 6 shown on diagram
    $1.09
  • 12 NUT, FLANGE

    NUT, FLANGE

    • Part No. 02763-50080
    • M8XP1.25
    • 4 shown on diagram
    $0.85
  • 13 WASHER PACKING v

    WASHER PACKING v

    • Part No. T4833-87141
    • 2 shown on diagram
    $2.49
  • 14 Bolt, Flange M8 P1.25

    Bolt, Flange M8 P1.25

    • Part No. 01754-50830
    • M8XP1.25
    • 2 shown on diagram
    $1.89
  • 15

    CEILING dnr v

    • Part No. T5310-82012
    • 1 shown on diagram
    $1,054.99
  • 16

    BRACKET, SUN VISOR

    • Part No. T4930-80141
    • Serial No. Up to KH2400003
    • *multiple options for # 16
    • 2 shown on diagram
    $12.99
  • 16 BRACKET, SUN VISOR

    BRACKET, SUN VISOR

    • Part No. T4930-80142
    • Compatibility No Interchange
    • Serial No. MH2400001 and up
    • *multiple options for # 16
    • 2 shown on diagram
    $11.99
  • 17

    SCREW

    • Part No. 03004-50620
    • Serial No. Up to KH2400003
    • *multiple options for # 17
    • 8 shown on diagram
    $0.73
  • 17

    SCREW

    • Part No. 03004-50620
    • Compatibility No Interchange
    • Serial No. MH2400001 and up
    • *multiple options for # 17
    • 12 shown on diagram
    $0.73
  • 18 Flat Washer M6

    Flat Washer M6

    • Part No. 04013-50060
    • Applied Dates 2007-10-01 and up
    • Serial No. Up to KH2400003
    • M6
    • *multiple options for # 18
    • 8 shown on diagram
    $0.73
  • 18 Flat Washer M6

    Flat Washer M6

    • Part No. 04013-50060
    • Compatibility No Interchange
    • Serial No. MH2400001 and up
    • M6
    • *multiple options for # 18
    • 12 shown on diagram
    $0.73
  • 19

    CAP RUBBER

    • Part No. T4145-82081
    • 12 shown on diagram
    $9.99
  • 20 NUT, SPRING

    NUT, SPRING

    • Part No. 38245-2925-3
    • Applied Dates Up to 2008-04-04
    • Serial No. Up to KH2400003
    • *multiple options for # 20
    • 6 shown on diagram
    $4.49
  • 20 NUT, SPRING

    NUT, SPRING

    • Part No. 38245-2925-3
    • Compatibility No Interchange
    • Serial No. MH2400001 and up
    • *multiple options for # 20
    • 12 shown on diagram
    $4.49
  • 21 CAB FILTER 10.75″ CC bolt pattern

    CAB FILTER 10.75″ CC bolt pattern

    • Part No. T4145-82052
    • 4 shown on diagram
    $61.99
  • 22 BOLT, RESIN M6 P1.00 x 13 v

    BOLT, RESIN M6 P1.00 x 13 v

    • Part No. 53415-4128-1
    • *multiple options for # 22
    • 8 shown on diagram
    $5.99
  • 22

    BOLT, Replaced by 55571-32381

    • Part No. 55571-3238-1
    • Compatibility New Replaces Old
    • *multiple options for # 22
    • 8 shown on diagram
    $0.00
  • 23

    GRILL, AIR

    • Part No. T4930-83091
    • T3.0
    • *multiple options for # 23
    • 1 shown on diagram
    $19.99
  • 23

    GRILL ASSY-RAD

    • Part No. T4145-83081
    • Compatibility No Interchange
    • *multiple options for # 23
    • 1 shown on diagram
    $159.99
  • 24

    SCREW

    • Part No. T4930-64301
    • 10 shown on diagram
    $0.79
  • 25

    COVER, ROOF FRONT

    • Part No. T4930-82062
    • Serial No. Up to KH2400003
    • *multiple options for # 25
    • 1 shown on diagram
    $199.99
  • 25

    COVER, FRONT-ROOF

    • Part No. T5310-82061
    • Compatibility No Interchange
    • Serial No. MH2400001 and up
    • T5.0
    • *multiple options for # 25
    • 1 shown on diagram
    $0.00
  • 25

    COVER, FRONT-ROOF

    • Part No. T5310-82062
    • Compatibility New Replaces Old
    • T5.0
    • *multiple options for # 25
    • 1 shown on diagram
    $129.99
  • 25

    COVER FRONT ROOF

    • Part No. T5310-82063
    • Compatibility New Replaces Old
    • T5.0
    • *multiple options for # 25
    • 1 shown on diagram
    $199.99
  • 26 Flange Bolt (T4625-55431)

    Flange Bolt (T4625-55431)

    • Part No. T4625-55431
    • Applied Dates 2011-12-30 to 2009-05-28
    • *multiple options for # 26
    • 8 shown on diagram
    $1.09
  • 26

    BOLT FLANGE

    • Part No. T4625-55441
    • Compatibility New Replaces Old
    • Applied Dates Up to 2011-12-29
    • *multiple options for # 26
    • 8 shown on diagram
    $2.49
  • 27

    RUBBER

    • Part No. T5310-83881
    • 1 shown on diagram
    $179.99
  • 28

    SPONGE

    • Part No. T4145-81531
    • Serial No. Up to KH2400003
    • *multiple options for # 28
    • 8 shown on diagram
    $11.99
  • 28 SPONGE

    SPONGE

    • Part No. T4145-81532
    • Compatibility Call for compatibility
    • Serial No. MH2400001 and up
    • *multiple options for # 28
    • 8 shown on diagram
    $11.99
  • 29

    BRACKET, CASSETTE FIXING

    • Part No. T4145-83191
    • 1 shown on diagram
    $15.99
  • 30 BOLT, FLANGE

    BOLT, FLANGE

    • Part No. 01754-50816
    • M8XP1.25
    • 1 shown on diagram
    $1.79
  • 31 MIRROR, ROOM

    MIRROR, ROOM

    • Part No. T4810-82811
    • 1 shown on diagram
    $59.99
  • 32

    USE Nut Cap #T4815-93211

    • Part No. T4815-83211
    • 1 shown on diagram
    $0.00
  • 33

    SUN VISOR v

    • Part No. T4930-80151
    • Applied Dates 2007-05-09 to 2008-06-12
    • *multiple options for # 33
    • 1 shown on diagram
    $219.99
  • 33

    SUN VISOR

    • Part No. T4135-80151
    • Compatibility Call for compatibility
    • Applied Dates 2008-08-11 and up
    • Serial No. HH2400019 and up
    • *multiple options for # 33
    • 1 shown on diagram
    $124.99
  • 33

    SUN VISOR v

    • Part No. T4920-80151
    • Compatibility Interchngable
    • Serial No. HH2400019 to KH2400003
    • *multiple options for # 33
    • 1 shown on diagram
    $69.99
  • 33

    SUN VISOR, Replaced by T4135-80151

    • Part No. T4920-80152
    • Compatibility Call for compatibility
    • Serial No. NH2400001 and up
    • *multiple options for # 33
    • 1 shown on diagram
    $0.00
  • 34

    GROMMET v

    • Part No. T4815-78112
    • 4 shown on diagram
    $3.99
  • 35 Element 17.5″ CC, offset bolt hole Cab Filter DK90

    Element 17.5″ CC, offset bolt hole Cab Filter DK90

    • Part No. T4930-81402
    • 2 shown on diagram
    $49.99
  • 36 ELEMENT 11.25″ CC, offset bolt holes Cab Filter DK90

    ELEMENT 11.25″ CC, offset bolt holes Cab Filter DK90

    • Part No. T4930-81412
    • 2 shown on diagram
    $57.99
