PTO SHAFT GROUP - EX45H-T285A

Kioti TRACTOR | DK Series | DK50HSE

Diagram for PTO SHAFT GROUP - EX45H-T285A
  • 1

    SHAFT, GEAR

    • Part No. T4125-25252
    • Applied Dates 2006-01-19 and up
    • 1 shown on diagram
    $399.99
  • 2 BEARING, BALL 35x80x21

    BEARING, BALL 35x80x21

    • Part No. 08101-06307
    • DIA35
    • 1 shown on diagram
    $41.99
  • 3

    CIR CLIP, EXTERNAL

    • Part No. T4810-25771
    • 2 shown on diagram
    $11.99
  • 4

    PLATE, SPACER

    • Part No. T2610-25191
    • T2.3
    • 1 shown on diagram
    $11.99
  • 5

    BOSS, SPLINE

    • Part No. T2610-25241
    • 1 shown on diagram
    $59.99
  • 6

    SHIFT

    • Part No. 38430-2175-1
    • 1 shown on diagram
    $89.99
  • 7

    GEAR

    • Part No. T4125-24162
    • Applied Dates Up to 2010-12-31
    • 1 shown on diagram
    $164.99
  • 8

    COLLAR, THRUST v

    • Part No. T2305-21762
    • T3.2
    • 1 shown on diagram
    $18.99
  • 9

    BEARING,BALL

    • Part No. 08101-06305
    • DIA25
    • 1 shown on diagram
    $24.99
  • 10 Snap Ring 30mm

    Snap Ring 30mm

    • Part No. 04612-00300
    • DIA30
    • 1 shown on diagram
    $1.59
  • 11

    RING, SNAP v

    • Part No. 38430-2554-1
    • 2 shown on diagram
    $7.49
  • 12

    DRIVING SHAFT, PTO

    • Part No. T4115-25261
    • 1 shown on diagram
    $254.99
  • 13 Ball Bearing 30x62x16

    Ball Bearing 30x62x16

    • Part No. 08101-06206
    • #6206
    • 2 shown on diagram
    $19.99
  • 14

    GEAR, Replaced by T4115-25272

    • Part No. T4115-25271
    • Applied Dates Up to 2007-11-23
    • *multiple options for # 14
    • 1 shown on diagram
    $0.00
  • 14

    GEAR

    • Part No. T4115-25272
    • Compatibility New Replaces Old
    • Applied Dates 2008-10-24 and up
    • *multiple options for # 14
    • 1 shown on diagram
    $164.99
  • 15

    WASHER

    • Part No. 38455-2314-1
    • 1 shown on diagram
    $4.99
  • 16 BEARING, BALL 30x55x13

    BEARING, BALL 30x55x13

    • Part No. 08101-06006
    • DIA30
    • 1 shown on diagram
    $23.99
  • 17

    COUPLING

    • Part No. T2610-25281
    • 1 shown on diagram
    $42.99
  • 18

    SHAFT,PTO OUTPUT v

    • Part No. T2610-25312
    • Applied Dates Up to 2006-12-31
    • *multiple options for # 18
    • 1 shown on diagram
    $139.99
  • 18

    SHAFT,PTO OUTPUT

    • Part No. T2610-25313
    • Compatibility Interchngable
    • Applied Dates 2007-11-22 and up
    • *multiple options for # 18
    • 1 shown on diagram
    $329.99
  • 19 COLLAR, OIL SEAL

    COLLAR, OIL SEAL

    • Part No. 35340-2535-1
    • 1 shown on diagram
    $9.99
  • 20

    SEAL, OIL v

    • Part No. T4240-25361
    • 1 shown on diagram
    $4.49
  • 21 BEARING, BALL, Replaced by T5210-06232

    BEARING, BALL, Replaced by T5210-06232

    • Part No. 38430-2533-1
    • Applied Dates Up to 2011-12-31
    • 62/32
    • *multiple options for # 21
    • 2 shown on diagram
    $0.00
  • 21 BALL BEARING

    BALL BEARING

    • Part No. T5210-06232
    • Compatibility Interchngable
    • Applied Dates 2012-02-17 and up
    • 62/32
    • *multiple options for # 21
    • 2 shown on diagram
    $39.99
  • 22 NUT

    NUT

    • Part No. 35340-2532-1
    • M32*1.5
    • 1 shown on diagram
    $15.99
  • 23 SLEEVE

    SLEEVE

    • Part No. T4260-25392
    • 1 shown on diagram
    $19.99
  • 24 OIL SEAL

    OIL SEAL

    • Part No. T4260-13161
    • 2 shown on diagram
    $5.99
  • 25 O RING

    O RING

    • Part No. 04811-50800
    • DIA79.4
    • 1 shown on diagram
    $1.69
  • 26

    CASE BEARING

    • Part No. T4260-25411
    • 1 shown on diagram
    $154.99
  • 27

    Bolt With Washer, M8 P1.25 x 32mm

    • Part No. 01123-50832
    • HEX12*43
    • 4 shown on diagram
    $2.49
  • 28

    Snap Ring

    • Part No. 04611-00650
    • DIA65
    • 1 shown on diagram
    $5.49
