SPEED SHIFT FORK GROUP - EX45H-T365A

Kioti TRACTOR | DK Series | DK50HSE

Diagram for SPEED SHIFT FORK GROUP - EX45H-T365A
  • 1

    FORK, USE T4125-23114

    • Part No. T4125-23111
    • Applied Dates Up to 2008-07-02
    • *multiple options for # 1
    • 1 shown on diagram
    $99.99
  • 1

    FORK, USE T4125-23114

    • Part No. T4125-23112
    • Compatibility Interchngable
    • Applied Dates Up to 2007-12-31
    • *multiple options for # 1
    • 1 shown on diagram
    $89.99
  • 1

    FORK, USE T4125-23114

    • Part No. T4125-23113
    • Compatibility Call for compatibility
    • Applied Dates Up to 2008-12-31
    • *multiple options for # 1
    • 1 shown on diagram
    $0.00
  • 1

    FORK v

    • Part No. T4125-23114
    • Compatibility Interchngable
    • Applied Dates Up to 2010-12-31
    • *multiple options for # 1
    • 1 shown on diagram
    $199.99
  • 1 Fork

    Fork

    • Part No. T4115-23111
    • Compatibility Interchngable
    • Applied Dates 2011-02-15 and up
    • *multiple options for # 1
    • 1 shown on diagram
    $124.99
  • 2

    ROD, FORK v

    • Part No. T4125-23121
    • Applied Dates Up to 2008-05-22
    • *multiple options for # 2
    • 1 shown on diagram
    $48.99
  • 2

    ROD, FORK v

    • Part No. T4125-23122
    • Compatibility Interchngable
    • Applied Dates Up to 2008-12-31
    • Serial No. Up to JS2800052
    • *multiple options for # 2
    • 1 shown on diagram
    $55.99
  • 2

    ROD, FORK v

    • Part No. T4125-23123
    • Compatibility Call for compatibility
    • Applied Dates Up to 2008-12-31
    • Serial No. JS2800053 and up
    • *multiple options for # 2
    • 1 shown on diagram
    $61.99
  • 2 ROD, FORK v

    ROD, FORK v

    • Part No. T4125-23124
    • Compatibility Interchngable
    • Applied Dates Up to 2010-12-31
    • *multiple options for # 2
    • 1 shown on diagram
    $86.99
  • 2

    ROD FORK v.o

    • Part No. T4115-23121
    • Compatibility Interchngable
    • Applied Dates Up to 2012-12-31
    • *multiple options for # 2
    • 1 shown on diagram
    $54.99
  • 2

    ROD FORK v

    • Part No. T4115-23122
    • Compatibility New Replaces Old
    • Applied Dates 2008-06-16 and up
    • *multiple options for # 2
    • 1 shown on diagram
    $83.99
  • 3 FRICTION SPRING V

    FRICTION SPRING V

    • Part No. 62331-1853-2
    • DIA1.4
    • 1 shown on diagram
    $3.49
  • 4 BALL,STEEL

    BALL,STEEL

    • Part No. 07715-01605
    • DIA7.9375
    • 1 shown on diagram
    $0.56
  • 5 PIN, SPRING

    PIN, SPRING

    • Part No. 05411-00625
    • DIA6.4XL25
    • 1 shown on diagram
    $1.09
  • 6

    SHIFT ARM v

    • Part No. T4125-23262
    • Applied Dates Up to 2008-05-22
    • *multiple options for # 6
    • 1 shown on diagram
    $27.99
  • 6

    SHIFT ARM

    • Part No. T4125-23263
    • Compatibility Interchngable
    • Applied Dates 2008-06-16 and up
    • *multiple options for # 6
    • 1 shown on diagram
    $49.99
  • 7 O RING

    O RING

    • Part No. 04811-00160
    • DIA15.8
    • 1 shown on diagram
    $1.09
  • 8

    STOPPER

    • Part No. T4620-44331
    • T2.0
    • 1 shown on diagram
    $9.99
  • 9 Bolt With Washer, M8 P1.25 x 16mm 01123-50816

    Bolt With Washer, M8 P1.25 x 16mm 01123-50816

    • Part No. 01123-50816
    • M8XP1.25
    • 1 shown on diagram
    $1.09
  • 10

    FORK, Replaced by T4125-24222

    • Part No. T4125-24221
    • Applied Dates Up to 2008-07-02
    • *multiple options for # 10
    • 1 shown on diagram
    $0.00
  • 10

    FORK

    • Part No. T4125-24222
    • Compatibility Interchngable
    • Applied Dates 2008-07-02 and up
    • *multiple options for # 10
    • 1 shown on diagram
    $144.99
  • 11

    ROD, FORK

    • Part No. T4125-24231
    • 1 shown on diagram
    $49.99
  • 12 FRICTION SPRING V

    FRICTION SPRING V

    • Part No. 62331-1853-2
    • DIA1.4
    • 1 shown on diagram
    $3.49
  • 13 BALL,STEEL

    BALL,STEEL

    • Part No. 07715-01605
    • DIA7.9375
    • 1 shown on diagram
    $0.56
  • 14

    SHIFT ARM

    • Part No. T4125-24251
    • 1 shown on diagram
    $47.99
  • 15 O RING

    O RING

    • Part No. 04811-00160
    • DIA15.8
    • 1 shown on diagram
    $1.09
  • 16

    STOPPER

    • Part No. T4620-44331
    • T2.0
    • 1 shown on diagram
    $9.99
  • 17 Bolt With Washer, M8 P1.25 x 16mm 01123-50816

    Bolt With Washer, M8 P1.25 x 16mm 01123-50816

    • Part No. 01123-50816
    • M8XP1.25
    • 1 shown on diagram
    $1.09
  • 18

    CONNECTING ARM (PTO)

    • Part No. T4115-24761
    • Applied Dates 2006-03-08 and up
    • 1 shown on diagram
    $22.99
  • 19 PIN, SPRING

    PIN, SPRING

    • Part No. 05411-00630
    • DIA6.4XL30
    • 1 shown on diagram
    $0.90
