ROPS GROUP - EX45H-T975A

Kioti TRACTOR | DK Series | DK50HSE

Diagram for ROPS GROUP - EX45H-T975A
  • 1

    ROPS v

    • Part No. T4125-97111
    • 75*50*T5.0
    • *multiple options for # 1
    • 1 shown on diagram
    $674.99
  • 1

    TRK – ROPS v, Replaced by T4125-97112BB

    • Part No. T4125-97112
    • Compatibility New Replaces Old
    • Applied Dates 2008-01-31 to 2008-11-10
    • Serial No. HS2800001 to GS2800002
    • 75*50*T5.0
    • *multiple options for # 1
    • 1 shown on diagram
    $0.00
  • 1

    ROPS v

    • Part No. T4125-97112BB
    • Compatibility No Interchange
    • Applied Dates 2008-01-31 and up
    • Serial No. HS2800001 and up
    • *multiple options for # 1
    • 1 shown on diagram
    $1,009.99
  • 2

    ASS’Y, ROPS SUPPORT(LH) dnr v

    • Part No. T4125-97123
    • Applied Dates 2006-05-31 to 2007-08-16
    • Serial No. FS2800001 and up
    • *multiple options for # 2
    • 1 shown on diagram
    $294.99
  • 2

    ASS’Y, ROPS SUPPORT(LH)

    • Part No. T4025-97121
    • Compatibility No Interchange
    • Applied Dates 2007-10-10 to 2008-11-18
    • Serial No. GS2800001 to HS2800016
    • *multiple options for # 2
    • 1 shown on diagram
    $229.99
  • 2

    SUPPORT ASSY, ROPS obs v

    • Part No. T4025-97121BB
    • Compatibility No Interchange
    • Serial No. HS2800017 and up
    • *multiple options for # 2
    • 1 shown on diagram
    $169.99
  • 3

    ASSY SUPPORT, ROPS-RH dnr v

    • Part No. T4125-97133
    • Applied Dates 2006-05-31 to 2007-08-16
    • Serial No. FS2800001 and up
    • *multiple options for # 3
    • 1 shown on diagram
    $299.99
  • 3

    ASS’Y, ROPS SUPPORT(RH)

    • Part No. T4025-97131
    • Compatibility No Interchange
    • Applied Dates 2007-10-10 to 2008-11-24
    • Serial No. GS2800001 to HS2800016
    • *multiple options for # 3
    • 1 shown on diagram
    $229.99
  • 3

    ASS’Y, ROPS SUPPORT(RH) obs v

    • Part No. T4025-97131BB
    • Compatibility No Interchange
    • Serial No. HS2800017 and up
    • *multiple options for # 3
    • 1 shown on diagram
    $169.99
  • 4

    SUPPORT,ROPS(LH) dnr v

    • Part No. T4125-97221
    • Applied Dates 2006-02-08 to 2007-08-16
    • *multiple options for # 4
    • 1 shown on diagram
    $244.99
  • 4

    SUPPORT, ROPS LH

    • Part No. T4025-97221
    • Compatibility No Interchange
    • *multiple options for # 4
    • 1 shown on diagram
    $264.99
  • 5

    SUPPORT, ROPS-RH obs

    • Part No. T4125-97231
    • Applied Dates 2006-02-08 to 2007-08-16
    • *multiple options for # 5
    • 1 shown on diagram
    $274.99
  • 5

    SUPPORT, ROPS RH dnr v, Replaced by T4025-97231BB

    • Part No. T4025-97231
    • Compatibility No Interchange
    • *multiple options for # 5
    • 1 shown on diagram
    $0.00
  • 6 BOLT,HINGE

    BOLT,HINGE

    • Part No. T4687-88041
    • 1 shown on diagram
    $17.99
  • 7 NUT

    NUT

    • Part No. T4687-88051
    • 1 shown on diagram
    $9.49
  • 8 BOLT V

    BOLT V

    • Part No. T2185-97182
    • 1 shown on diagram
    $34.99
  • 9 NUT

    NUT

    • Part No. 02074-50120
    • M12XP1.25
    • 1 shown on diagram
    $0.85
  • 10

    ASSY PIN

    • Part No. T4125-97161
    • 1 shown on diagram
    $57.99
  • 11

    SUPPORT FENDER (LH) v

    • Part No. T4125-95033
    • Applied Dates 2006-06-01 to 2006-12-30
    • *multiple options for # 11
    • 1 shown on diagram
    $324.99
  • 11

    SUPPORT FENDER (LH) v

    • Part No. T4125-95034
    • Compatibility New Replaces Old
    • Applied Dates 2006-12-31 to 2008-02-28
    • Serial No. FS2800001 and up
    • *multiple options for # 11
    • 1 shown on diagram
    $314.99
  • 11

    SUPPORT FENDER (LH) v, Replaced by T4125-95035BB

    • Part No. T4125-95035
    • Compatibility New Replaces Old
    • Applied Dates 2008-02-29 to 2009-04-05
    • Serial No. HS2800001 to JS2800032
    • *multiple options for # 11
    • 1 shown on diagram
    $0.00
  • 11

    SUPPORT FENDER LH

    • Part No. T4125-95035BB
    • Compatibility No Interchange
    • Applied Dates 2009-04-06 and up
    • Serial No. JS2800033 and up
    • *multiple options for # 11
    • 1 shown on diagram
    $574.99
  • 11

    SUPPORT, FENDER LH

    • Part No. T4125-95036
    • Compatibility New Replaces Old
    • *multiple options for # 11
    • 1 shown on diagram
    $574.99
  • 12

    SUPPORT, FENDER (RH) v

    • Part No. T4125-95043
    • Applied Dates 2006-06-01 to 2006-12-30
    • *multiple options for # 12
    • 1 shown on diagram
    $324.99
  • 12

    SUPPORT, FENDER (RH) v

    • Part No. T4125-95044
    • Compatibility New Replaces Old
    • Applied Dates 2006-12-31 to 2008-02-28
    • Serial No. FS2800001 and up
    • *multiple options for # 12
    • 1 shown on diagram
    $314.99
  • 12

    SUPPORT, FENDER (RH) v, Replaced by T4125-95046

    • Part No. T4125-95045
    • Compatibility New Replaces Old
    • Applied Dates 2008-02-29 to 2009-04-05
    • Serial No. HS2800001 to JS2800032
    • *multiple options for # 12
    • 1 shown on diagram
    $0.00
  • 12

    SUPPORT FENDER RH, Replaced by T4125-95046

    • Part No. T4125-95045BB
    • Compatibility No Interchange
    • Applied Dates 2009-04-06 and up
    • Serial No. JS2800033 and up
    • *multiple options for # 12
    • 1 shown on diagram
    $0.00
  • 12

    SUPPORT, FENDER RH

    • Part No. T4125-95046
    • Compatibility New Replaces Old
    • *multiple options for # 12
    • 1 shown on diagram
    $554.99
  • 13

    Hex Head Cap Screw M14 P1.5×40

    • Part No. 01173-51440
    • M14XP1.5
    • 8 shown on diagram
    $3.49
  • 14

    M14 Spring Lock Washer 04512-50140

    • Part No. 04512-50140
    • M14
    • 8 shown on diagram
    $0.90
  • 15

    HOLDER,CHECK CHAIN v

    • Part No. T4373-97142
    • Compatibility New Replaces Old
    • Applied Dates 2008-04-11 to 2008-10-22
    • *multiple options for # 15
    • 2 shown on diagram
    $289.99
  • 15

    HOLDER CHECK CHAIN v

    • Part No. T4373-97142ED
    • Compatibility No Interchange
    • Serial No. LS2800012 and up
    • *multiple options for # 15
    • 2 shown on diagram
    $289.99
  • 17

    M14 Spring Lock Washer 04512-50140

    • Part No. 04512-50140
    • M14
    • 16 shown on diagram
    $0.90
  • 18

    CUSHION T2670-74431

    • Part No. T2670-74431
    • *multiple options for # 18
    • 4 shown on diagram
    $13.99
  • 18

    CUSHION T2670-74432

    • Part No. T2670-74432
    • Compatibility New Replaces Old
    • Applied Dates 2007-05-01 and up
    • *multiple options for # 18
    • 4 shown on diagram
    $19.99
  • 19

    STOPPER v

    • Part No. T2350-85151BB
    • Compatibility No Interchange
    • Serial No. JS2800033 and up
    • 4 shown on diagram
    $16.99
  • 20

    SPACER obs v

    • Part No. T4125-85171
    • Applied Dates 2006-07-19 to 2007-03-12
    • *multiple options for # 20
    • 2 shown on diagram
    $6.99
  • 20

    Spacer (T2350-85171)

    • Part No. T2350-85171
    • Compatibility Call for compatibility
    • Applied Dates 2007-05-01 and up
    • Serial No. GS2800001 and up
    • DIA22.4*T4.0
    • *multiple options for # 20
    • 2 shown on diagram
    $12.99
  • 21

    COLLAR

    • Part No. T4125-74451
    • T3.0
    • 2 shown on diagram
    $7.49
  • 22

    BOLT 01173-51490

    • Part No. 01173-51490
    • Applied Dates 2005-10-11 to 2007-05-24
    • Serial No. ES2800001 and up
    • M14XP1.5
    • *multiple options for # 22
    • 2 shown on diagram
    $9.99
  • 22

    BOLT

    • Part No. 01173-51601
    • Compatibility Interchangeable
    • Applied Dates 2007-05-25 to 2007-06-21
    • M16XP1.5
    • *multiple options for # 22
    • 2 shown on diagram
    $11.99
  • 22

    BOLT

    • Part No. 01173-51400
    • Compatibility New Replaces Old
    • Applied Dates 2007-07-01 and up
    • Serial No. GS2800001 and up
    • M14XP1.5
    • *multiple options for # 22
    • 2 shown on diagram
    $8.49
  • 23

    M14 Spring Lock Washer 04512-50140

    • Part No. 04512-50140
    • M14
    • 2 shown on diagram
    $0.90
  • 24 Flat Washer M14

    Flat Washer M14

    • Part No. 04014-50140
    • M14
    • 2 shown on diagram
    $1.29
  • 25 NUT

    NUT

    • Part No. 02076-50140
    • M14XP1.5
    • 2 shown on diagram
    $1.79
  • 26

    Hex Head Cap Screw M14 P1.5×40

    • Part No. 01173-51440
    • M14XP1.5
    • 6 shown on diagram
    $3.49
  • 27

    BOLT

    • Part No. 01173-51445
    • M14XP1.5
    • 2 shown on diagram
    $7.99
  • 28

    M14 Spring Lock Washer 04512-50140

    • Part No. 04512-50140
    • M14
    • 8 shown on diagram
    $0.90
  • 29 Flat Washer M14

    Flat Washer M14

    • Part No. 04014-50140
    • M14
    • 8 shown on diagram
    $1.29
  • 30 BOLT, FLANGE

    BOLT, FLANGE

    • Part No. 01754-50816
    • M8XP1.25
    • 2 shown on diagram
    $1.79
  • 31

    NUT CAP, Replaced by T4125-93312

    • Part No. T4125-93311
    • Applied Dates 2006-06-01 to 2006-12-09
    • *multiple options for # 31
    • 2 shown on diagram
    $0.00
  • 31

    NUT CAP

    • Part No. T4125-93312
    • Compatibility Interchangeable
    • Applied Dates 2006-12-10 to 2008-04-10
    • Serial No. FS2800001 and up
    • *multiple options for # 31
    • 2 shown on diagram
    $4.99
