DISPLAY CONTROL GROUP - TD2-G533001

Kioti TRACTOR | DK Series | DK5010HS

Diagram for DISPLAY CONTROL GROUP - TD2-G533001
  • 1 TAPPING SCREW v

    TAPPING SCREW v

    • Part No. 38240-1883-1
    • M4X16
    • 6 shown on diagram
    $0.79
  • 2 MICRO SWITCH N/C

    MICRO SWITCH N/C

    • Part No. T2198-68811
    • DC30V 3A
    • 1 shown on diagram
    $64.99
  • 3 MICRO SWITCH

    MICRO SWITCH

    • Part No. T5535-69281
    • 1 shown on diagram
    $68.99
  • 4

    NUT

    • Part No. 02054-50020
    • M2*P0.4
    • 2 shown on diagram
    $0.55
  • 5 BOLT

    BOLT

    • Part No. 03054-50214
    • M2*P0.4*L14
    • 2 shown on diagram
    $0.50
  • 6

    WASHER, SPRING obs v

    • Part No. 04512-50020
    • M2
    • 2 shown on diagram
    $0.56
  • 7

    ASSY PLATE, METER dnr v

    • Part No. T5730-69012
    • Applied Dates Up to 2016-10-13
    • *multiple options for # 7
    • 1 shown on diagram
    $494.99
  • 7

    ASSY PLATE, METER, Replaced by T5730-69017

    • Part No. T5730-69013
    • Compatibility New Replaces Old
    • Applied Dates 2016-10-14 and up
    • Serial No. SR8100001 to UR8100026
    • *multiple options for # 7
    • 1 shown on diagram
    $0.00
  • 7

    ASSY PLATE,METER

    • Part No. T5730-69014
    • Compatibility New Replaces Old
    • Applied Dates 2018-06-20 to 2018-08-31
    • *multiple options for # 7
    • 1 shown on diagram
    $0.00
  • 7

    ASSY PLATE,METER

    • Part No. T5730-69015
    • Compatibility New Replaces Old
    • Applied Dates 2018-09-01 to 2019-02-28
    • Serial No. UR8100027 and up
    • *multiple options for # 7
    • 1 shown on diagram
    $0.00
  • 7

    ASSY METER, INSTRUMENT DIAL dnr v, Replaced by T5730-69017

    • Part No. T5730-69016
    • Compatibility New Replaces Old
    • Applied Dates 2019-03-01 and up
    • Serial No. VR8100001 and up
    • *multiple options for # 7
    • 1 shown on diagram
    $0.00
  • 7

    ASSY PLATE, METER

    • Part No. T5730-69017
    • Compatibility Interchangeable
    • *multiple options for # 7
    • 1 shown on diagram
    $639.99
