CYLINDER HEAD GROUP - 4B243LW-E030

Kioti TRACTOR | DK Series | DK50SE

Diagram for CYLINDER HEAD GROUP - 4B243LW-E030
  • 1

    VALVE, JOYSTICK-CAB

    • Part No. E6853-03041
    • *multiple options for # 1
    • 1 shown on diagram
    $1,484.99
  • 1

    ASSY HEAD,CYLINDER v

    • Part No. E6853-03042
    • Compatibility New Replaces Old
    • *multiple options for # 1
    • 1 shown on diagram
    $1,484.99
  • 2 CAP SEALING

    CAP SEALING

    • Part No. 15221-0337-3
    • T1.6*40*40
    • 12 shown on diagram
    $3.49
  • 3

    CAP SEALING 35mm

    • Part No. 15221-0349-3
    • T1.6*60*60
    • 1 shown on diagram
    $4.49
  • 4 PLUG, Replaced by E5900-96022

    PLUG, Replaced by E5900-96022

    • Part No. E5900-96021
    • *multiple options for # 4
    • 2 shown on diagram
    $4.99
  • 4 PLUG

    PLUG

    • Part No. E5900-96022
    • Compatibility Interchangeable
    • *multiple options for # 4
    • 2 shown on diagram
    $3.99
  • 5 GUIDE,INLET VALVE v

    GUIDE,INLET VALVE v

    • Part No. E6850-13581
    • 4 shown on diagram
    $6.99
  • 6 GUIDE,EXHAUST VALVE v

    GUIDE,EXHAUST VALVE v

    • Part No. E6850-13561
    • 4 shown on diagram
    $8.49
  • 7

    PLUG HOT COMBUSTION CHAMBER

    • Part No. E6500-03142
    • 4 shown on diagram
    $81.99
  • 8

    Engine Hook (15221-0175-1)

    • Part No. 15221-0175-1
    • T4*40*64
    • 2 shown on diagram
    $3.99
  • 9 Bolt With Washer, M8 P1.25 x 16mm 01123-50816

    Bolt With Washer, M8 P1.25 x 16mm 01123-50816

    • Part No. 01123-50816
    • M8XP1.25
    • 1 shown on diagram
    $1.09
  • 10

    BOLT, HEAD v

    • Part No. E6300-03453
    • Applied Dates Up to 2008-11-10
    • *multiple options for # 10
    • 18 shown on diagram
    $7.99
  • 10 Bolt, Head M11 P1.25 Stretch Type

    Bolt, Head M11 P1.25 Stretch Type

    • Part No. E6850-03451
    • Compatibility New Replaces Old
    • M11×1.25P
    • *multiple options for # 10
    • 18 shown on diagram
    $9.99
  • 11

    CYLINDERHEAD GASKET, Replaced by E6850-03312

    • Part No. E6850-03311
    • *multiple options for # 11
    • 1 shown on diagram
    $95.33
  • 11

    GASKET, CYLINDER HEAD v

    • Part No. E6850-03312
    • Compatibility Interchangeable
    • *multiple options for # 11
    • 1 shown on diagram
    $134.99
  • 12 PLUG, Replaced by E5900-96022

    PLUG, Replaced by E5900-96022

    • Part No. E5900-96021
    • *multiple options for # 12
    • 1 shown on diagram
    $4.99
  • 12 PLUG

    PLUG

    • Part No. E5900-96022
    • Compatibility Interchangeable
    • *multiple options for # 12
    • 1 shown on diagram
    $3.99
  • 13 STUD

    STUD

    • Part No. 01513-50822
    • M8XP1.25
    • 1 shown on diagram
    $3.99
  • 14 Nut M8 P1.25

    Nut M8 P1.25

    • Part No. 02156-50080
    • Applied Dates 2015-07-12 to 2008-07-22
    • M8XP1.25
    • *multiple options for # 14
    • 1 shown on diagram
    $0.85
  • 14 NUT, FLANGE

    NUT, FLANGE

    • Part No. 02763-50080
    • Compatibility Interchangeable
    • Applied Dates 2013-06-26 to 2013-05-04
    • M8XP1.25
    • *multiple options for # 14
    • 1 shown on diagram
    $0.85
  • 15 Spring Lock Washer M8

    Spring Lock Washer M8

    • Part No. 04512-50080
    • Applied Dates Up to 2008-07-22
    • M08
    • 1 shown on diagram
    $0.61
