LEVER GUIDE(ROPS) GROUP - TD2-G637003

Kioti TRACTOR | DK Series | DK5010

Diagram for LEVER GUIDE(ROPS) GROUP - TD2-G637003
  • 1

    TRK FENDER ASSY LH dnr v

    • Part No. T5710-52614
    • Applied Dates 2014-09-24 to 2018-05-13
    • Serial No. PR8000001 to UR8000022
    • *multiple options for # 1
    • 1 shown on diagram
    $699.99
  • 1

    ASSY FENDER-LH dnr v, Replaced by T5710-52615OE

    • Part No. T5710-52615
    • Compatibility New Replaces Old
    • Applied Dates 2018-05-01 to 2019-12-08
    • Serial No. UR8000023 to VR8000143
    • *multiple options for # 1
    • 1 shown on diagram
    $539.39
  • 1

    TRK – FENDER ASSY, LH

    • Part No. T5710-52615OE
    • Compatibility New Replaces Old
    • *multiple options for # 1
    • 1 shown on diagram
    $699.99
  • 2 BOLT, FLANGE

    BOLT, FLANGE

    • Part No. 01754-50816
    • M8XP1.25
    • 14 shown on diagram
    $1.79
  • 3 Kioti Flange Nut, M8 P1.25

    Kioti Flange Nut, M8 P1.25

    • Part No. 02751-50080
    • M8XP1.25
    • 1 shown on diagram
    $0.67
  • 4

    TRK – FENDER ASSY RH dnr v, Replaced by T5710-52624OE

    • Part No. T5710-52624
    • Applied Dates 2014-09-24 to 2019-12-08
    • Serial No. PR8000001 to VR8000143
    • *multiple options for # 4
    • 1 shown on diagram
    $0.00
  • 4

    TRK – FENDER ASSY, RH

    • Part No. T5710-52624OE
    • Compatibility New Replaces Old
    • *multiple options for # 4
    • 1 shown on diagram
    $709.99
  • 5 BOLT, FLANGE

    BOLT, FLANGE

    • Part No. 01754-50816
    • M8XP1.25
    • 14 shown on diagram
    $1.79
  • 6 Kioti Flange Nut, M8 P1.25

    Kioti Flange Nut, M8 P1.25

    • Part No. 02751-50080
    • M8XP1.25
    • 1 shown on diagram
    $0.67
  • 7 GRIP

    GRIP

    • Part No. T2630-95052
    • 2 shown on diagram
    $59.99
  • 8 NUT, FLANGE

    NUT, FLANGE

    • Part No. 02763-50080
    • M8XP1.25
    • 4 shown on diagram
    $0.85
  • 9

    LEVER GUIDE, LH

    • Part No. T5710-52651
    • *multiple options for # 9
    • 1 shown on diagram
    $76.99
  • 9

    LEVER GUIDE, LH

    • Part No. T5710-52652
    • Compatibility Interchangeable
    • Applied Dates 2014-12-31 to 2015-09-30
    • Serial No. PR8000187 and up
    • T3.0
    • *multiple options for # 9
    • 1 shown on diagram
    $83.99
  • 9

    LEVER GUIDE, LH dnr v, Replaced by T5710-52653FB

    • Part No. T5710-52653
    • Compatibility No Interchange
    • Applied Dates 2019-12-14 to 2020-01-06
    • Serial No. VR8000155 and up
    • T3.0
    • *multiple options for # 9
    • 1 shown on diagram
    $0.00
  • 9

    GUIDE, LEVER-LH

    • Part No. T5710-52654
    • Compatibility New Replaces Old
    • T3.0
    • *multiple options for # 9
    • 1 shown on diagram
    $0.00
  • 9

    GUIDE, LEVER-LH

    • Part No. T5710-52655
    • Compatibility New Replaces Old
    • T3.0
    • *multiple options for # 9
    • 1 shown on diagram
    $0.00
  • 10

    GUIDE, LEVER(ROPS)-RH dnr v, Replaced by T5710-52664

    • Part No. T5710-52662
    • Applied Dates 2014-08-04 to 2015-01-25
    • *multiple options for # 10
    • 1 shown on diagram
    $0.00
  • 10

    LEVER GUIDE, RH

    • Part No. T5710-52663
    • Compatibility Call for compatibility
    • Applied Dates 2015-01-26 to 2015-09-30
    • *multiple options for # 10
    • 1 shown on diagram
    $79.99
  • 10

    GUIDE, LEVER-RH dnr v, Replaced by T5710-52664FB

    • Part No. T5710-52664
    • Compatibility No Interchange
    • Applied Dates 2019-12-14 to 2020-01-06
    • Serial No. VR8000155 and up
    • *multiple options for # 10
    • 1 shown on diagram
    $0.00
  • 11 Flange Bolt (T4625-55431)

    Flange Bolt (T4625-55431)

    • Part No. T4625-55431
    • 7 shown on diagram
    $1.09
  • 12

    CLAMP

    • Part No. 37150-3447-1
    • T0.5
    • 2 shown on diagram
    $4.99
  • 13

    BOLT, Replaced by 55571-32381

    • Part No. 55571-3238-1
    • 1 shown on diagram
    $0.00
  • 14 Flat Washer M6, Replaced by 04012-50060

    Flat Washer M6, Replaced by 04012-50060

    • Part No. 04015-50060
    • M6
    • 1 shown on diagram
    $0.00
  • 15 Split Pin (05511-50215)

    Split Pin (05511-50215)

    • Part No. 05511-50215
    • DIA1.8XL15
    • 1 shown on diagram
    $0.62
  • 16

    SPACER

    • Part No. T4520-83301
    • DIA10.5*T2.0
    • 1 shown on diagram
    $4.99
  • 17

    Lever Stopper (T2350-95472)

    • Part No. T2350-95472
    • 1 shown on diagram
    $3.49
