BRAKE ROD GROUP - DK55HSE-T825A

Kioti TRACTOR | DK Series | DK60HSE

Diagram for BRAKE ROD GROUP - DK55HSE-T825A
  • 1

    TURNBUCKLE

    • Part No. 32350-2898-4
    • HEX14
    • 2 shown on diagram
    $28.99
  • 2 Nut M10 P1.25

    Nut M10 P1.25

    • Part No. 02176-50100
    • M10XP1.25
    • 2 shown on diagram
    $0.98
  • 3

    BRAKE ROD 2

    • Part No. T2185-55761
    • 2 shown on diagram
    $19.99
  • 4

    Pin, Joint M10x28mm

    • Part No. 05122-51028
    • DIA10XL28
    • 2 shown on diagram
    $3.49
  • 5 Flat Washer M10

    Flat Washer M10

    • Part No. 04013-50100
    • M10
    • 2 shown on diagram
    $0.73
  • 6

    Split Pin (05511-50318)

    • Part No. 05511-50318
    • DIA2.7XL18
    • 2 shown on diagram
    $0.40
  • 7

    ROD 2,BRAKE

    • Part No. T4157-55771
    • 2 shown on diagram
    $57.99
  • 8 Pin, Joint M8x28mm

    Pin, Joint M8x28mm

    • Part No. 05122-50828
    • DIA8XL28
    • 4 shown on diagram
    $3.49
  • 9 Flat Washer M8

    Flat Washer M8

    • Part No. 04013-50080
    • 4 shown on diagram
    $0.79
  • 10 PIN, SPLIT

    PIN, SPLIT

    • Part No. 05511-50218
    • DIA1.8XL18
    • 4 shown on diagram
    $0.56
