AIRCONE BRACKET - DK60CHSE-T045A

Kioti TRACTOR | DK Series | DK60CHSE

  • 1

    BRACKET,COMPRESSOR

    • Part No. T5517-72082
    • 1 shown on diagram
    $144.99
  • 2 Bolt With Washer, M8 P1.25 x 20mm

    Bolt With Washer, M8 P1.25 x 20mm

    • Part No. 01123-50820
    • M8XP1.25
    • 2 shown on diagram
    $2.49
  • 3 Bolt With Washer, M8 P1.25 x 20mm

    Bolt With Washer, M8 P1.25 x 20mm

    • Part No. 01123-50820
    • M8XP1.25
    • 3 shown on diagram
    $2.49
  • 4 Kioti Flange Nut, M8 P1.25

    Kioti Flange Nut, M8 P1.25

    • Part No. 02751-50080
    • M8XP1.25
    • 1 shown on diagram
    $0.67
  • 5 SHAFT, PULLEY

    SHAFT, PULLEY

    • Part No. E7300-05304
    • 1 shown on diagram
    $17.99
  • 6 BEARING, BALL

    BEARING, BALL

    • Part No. E7310-76191
    • 1 shown on diagram
    $15.99
  • 7

    Pulley, Replaced by E2101-05312BB

    • Part No. E2101-05312
    • 1 shown on diagram
    $0.00
  • 8 CIR CLIP, INTERNAL

    CIR CLIP, INTERNAL

    • Part No. 04611-00350
    • SK5M
    • 1 shown on diagram
    $1.39
  • 9

    COLLAR

    • Part No. 76KB-0511
    • DIA25*10
    • 1 shown on diagram
    $4.99
  • 10

    BOLT, TENSION dnr v

    • Part No. E7310-76161
    • 1 shown on diagram
    $22.99
  • 11

    WASHER

    • Part No. 76KB-0512
    • 10.5*22*T3.2
    • 1 shown on diagram
    $2.49
  • 12 Lock Washer M10

    Lock Washer M10

    • Part No. 04512-50100
    • M10
    • 1 shown on diagram
    $0.79
  • 13

    NUT

    • Part No. 02018-50100
    • M10*P1.25
    • 3 shown on diagram
    $0.73
  • 14 BELT, AIRCON 58.5

    BELT, AIRCON 58.5

    • Part No. T4345-72102
    • REC A-58.5
    • 1 shown on diagram
    $32.99
  • 15

    HOLDER, SHUTTLE

    • Part No. T5517-81221
    • 1 shown on diagram
    $0.00
  • 16

    BOLT, FLANGE

    • Part No. 01754-50840
    • 1 shown on diagram
    $2.49
  • 17 FLANGE BOLT, HEX HEAD M8

    FLANGE BOLT, HEX HEAD M8

    • Part No. 01754-50820
    • M8XP1.25
    • 1 shown on diagram
    $1.19
  • 18 Nut, Flange, M6 P1.00 02751-50060

    Nut, Flange, M6 P1.00 02751-50060

    • Part No. 02751-50060
    • M6XP1.0
    • 1 shown on diagram
    $0.73
