ACCELERATOR GROUP - CK30H-T860A

Kioti TRACTOR | CK Series | CK25H

Diagram for ACCELERATOR GROUP - CK30H-T860A
  • 1

    ACCEL,LEVER

    • Part No. T2185-60083
    • Applied Dates 2004-02-26 to 2004-06-15
    • Serial No. D70200152 to D70200501
    • * multiple options for #1
    • 1 shown on diagram
    $29.99
  • 1

    ACCEL LEVER

    • Part No. T2185-60084
    • Compatibility Interchngable
    • Applied Dates 2004-06-16 to 2004-07-21
    • * multiple options for #1
    • 1 shown on diagram
    $24.99
  • 1

    ACCEL LEVER

    • Part No. T2185-60085
    • Compatibility Interchngable
    • Applied Dates 2004-07-22 to 2007-04-01
    • Serial No. D70200502 to G70200040
    • * multiple options for #1
    • 1 shown on diagram
    $29.99
  • 2

    Lining

    • Part No. T2185-60091
    • 1 shown on diagram
    $19.99
  • 3 Flat Washer M12

    Flat Washer M12

    • Part No. 04013-50120
    • M12
    • 1 shown on diagram
    $0.85
  • 4

    SPRING

    • Part No. T4835-17241
    • 2 shown on diagram
    $4.49
  • 5

    NUT

    • Part No. 02174-50120
    • Applied Dates 2004-02-26 and up
    • M12*P1.25
    • 2 shown on diagram
    $0.85
  • 6

    CABLE, HAND ACCEL dnr v

    • Part No. T2185-60021
    • Applied Dates Up to 2004-05-10
    • * multiple options for #6
    • 1 shown on diagram
    $27.99
  • 6 CABEL, HAND ACCEL V

    CABEL, HAND ACCEL V

    • Part No. T2185-60022
    • Compatibility Interchngable
    • Applied Dates 2004-05-11 to 2005-01-17
    • Serial No. D70200402 to E70200080
    • * multiple options for #6
    • 1 shown on diagram
    $49.99
  • 6

    CABLE, HAND ACCEL v

    • Part No. T2185-60023
    • Compatibility No interchange
    • Applied Dates 2005-01-18 to 2007-04-01
    • Serial No. E70200081 to G70200040
    • * multiple options for #6
    • 1 shown on diagram
    $49.99
  • 7 Flat Washer M6

    Flat Washer M6

    • Part No. 04013-50060
    • M6
    • 1 shown on diagram
    $0.73
  • 8

    PIN, SNAP

    • Part No. 05525-50600
    • DIA6
    • 1 shown on diagram
    $1.19
  • 9

    GRIP(HAND ACCEL) v

    • Part No. T2615-60142
    • 1 shown on diagram
    $28.99
  • 10 BOOT

    BOOT

    • Part No. T4625-65571
    • Applied Dates 2004-01-08 and up
    • 1 shown on diagram
    $8.99
  • 11

    BRACKET

    • Part No. T4686-60082
    • Applied Dates Up to 2005-04-11
    • 1 shown on diagram
    $49.99
  • 12

    Accel Lever Obs V

    • Part No. T2185-60141
    • Applied Dates 2004-01-13 to 2005-04-11
    • 1 shown on diagram
    $65.99
  • 13

    Flat Washer M12

    • Part No. 04011-50120
    • Applied Dates Up to 2005-04-11
    • M12
    • 1 shown on diagram
    $0.73
  • 14

    RING,SNAP

    • Part No. 04612-00120
    • Applied Dates Up to 2005-04-11
    • #12
    • 1 shown on diagram
    $0.79
  • 15

    GROMMET

    • Part No. T4682-55801
    • Applied Dates Up to 2005-04-11
    • 1 shown on diagram
    $3.99
