SPEED SHIFT FORK GROUP - CK30M-T230A

Kioti TRACTOR | CK Series | CK25

Diagram for SPEED SHIFT FORK GROUP - CK30M-T230A
  • 1

    34-15 GEAR

    • Part No. T2185-23511
    • Applied Dates Up to 2004-07-05
    • Serial No. Up to D70100104
    • * multiple options for #1
    • 1 shown on diagram
    $189.99
  • 1

    GEAR, 34-15

    • Part No. T2185-23512
    • Compatibility No interchange
    • Applied Dates 2004-10-20 and up
    • Serial No. D70100105 and up
    • * multiple options for #1
    • 1 shown on diagram
    $329.99
  • 2 Bearing 6207 35x72x17

    Bearing 6207 35x72x17

    • Part No. 08101-06207
    • DIA35
    • 1 shown on diagram
    $28.99
  • 3

    COVER, BEARING

    • Part No. T2185-23312
    • Applied Dates Up to 2004-12-31
    • * multiple options for #3
    • 1 shown on diagram
    $169.99
  • 3

    COVER, BEARING

    • Part No. T2185-23313
    • Compatibility New repl old
    • Applied Dates 2005-03-14 and up
    • * multiple options for #3
    • 1 shown on diagram
    $169.99
  • 4

    WASHER BOLT v

    • Part No. 01133-51040
    • M10XP1.25
    • 6 shown on diagram
    $3.49
  • 5 PIN, STRAIGHT 05012-01018

    PIN, STRAIGHT 05012-01018

    • Part No. 05012-01018
    • Applied Dates Up to 2005-09-23
    • DIA10XL18
    • 2 shown on diagram
    $1.79
  • 6

    Range Shaft

    • Part No. T2185-23684
    • Applied Dates Up to 2005-09-23
    • Serial No. Up to E70100080
    • * multiple options for #6
    • 1 shown on diagram
    $75.99
  • 6

    SHAFT,RANGE

    • Part No. T2185-23685
    • Compatibility No interchange
    • Applied Dates Up to 2007-05-28
    • Serial No. E70100081 to G70100180
    • * multiple options for #6
    • 1 shown on diagram
    $64.99
  • 6

    SHAFT,SUBMISSION

    • Part No. T2185-23686
    • Compatibility No interchange
    • Applied Dates 2007-05-28 and up
    • Serial No. G70100181 and up
    • * multiple options for #6
    • 1 shown on diagram
    $109.99
  • 7 RING,SNAP

    RING,SNAP

    • Part No. 04611-00720
    • DIA72
    • 1 shown on diagram
    $7.99
  • 8 BEARING, BALL 6306

    BEARING, BALL 6306

    • Part No. 08101-06306
    • DIA30
    • 1 shown on diagram
    $29.99
  • 9

    COLLAR,THRUST dnr v

    • Part No. T2305-21761
    • Applied Dates Up to 2003-12-31
    • T3.2
    • * multiple options for #9
    • 1 shown on diagram
    $12.99
  • 9

    COLLAR, THRUST v

    • Part No. T2305-21762
    • Compatibility New repl old
    • Applied Dates 2004-05-31 and up
    • T3.2
    • * multiple options for #9
    • 1 shown on diagram
    $18.99
  • 10 Snap Ring 30mm

    Snap Ring 30mm

    • Part No. 04612-00300
    • Applied Dates 2004-07-02 and up
    • DIA30
    • 1 shown on diagram
    $1.59
  • 11

    Inner Ring

    • Part No. T2185-23691
    • Applied Dates Up to 2007-05-28
    • Serial No. Up to G70100180
    • * multiple options for #11
    • 1 shown on diagram
    $58.99
  • 11 BEARING, NEEDLE

    BEARING, NEEDLE

    • Part No. 08822-53020
    • Compatibility No interchange
    • Applied Dates 2006-09-26 to 2005-07-31
    • Serial No. G70100181 to E70100170
    • Inner diameter 25
    • * multiple options for #11
    • 1 shown on diagram
    $16.99
  • 12

    Gear 37 Tooth

    • Part No. T2185-23621
    • Applied Dates Up to 2004-07-05
    • Serial No. Up to E70100080
    • * multiple options for #12
    • 1 shown on diagram
    $129.99
  • 12

    GEAR,37

    • Part No. T2185-23622
    • Compatibility No interchange
    • Applied Dates Up to 2007-05-28
    • Serial No. E70100081 to G70100180
    • * multiple options for #12
    • 1 shown on diagram
    $119.99
  • 12

    GEAR 37

    • Part No. T2185-23623
    • Compatibility No interchange
    • Applied Dates 2007-05-28 and up
    • Serial No. G70100181 and up
    • * multiple options for #12
    • 1 shown on diagram
    $174.99
  • 13

    BOSS,SPLINE

    • Part No. T2185-23671
    • Applied Dates Up to 2005-09-23
    • * multiple options for #13
    • 1 shown on diagram
    $46.99
  • 13

    Splined Boss

    • Part No. T2185-23672
    • Compatibility Interchngable
    • Applied Dates 2005-12-17 and up
    • * multiple options for #13
    • 1 shown on diagram
    $51.99
  • 14

    SHIFTER

    • Part No. T4620-23681
    • 1 shown on diagram
    $109.99
  • 15

    CIR-CLIP

    • Part No. T2185-23701
    • Applied Dates 2006-09-26 and up
    • 2 shown on diagram
    $7.49
  • 16

    COUPLING

    • Part No. 37805-4452-1
    • 1 shown on diagram
    $52.99
  • 17 PIN, SPRING

    PIN, SPRING

    • Part No. 05411-00636
    • Applied Dates 2003-12-30 and up
    • 1 shown on diagram
    $0.90
